Halogen-Worklight - Modul 70 - 12V

Hella Part no. A25-005562 Previously PT/996176181

Halogen-Worklight - Modul 70 - 12V

Shop rating 4.3, from 4 customer reviews of Agri Lighting
£40.62 ex VAT
£48.74 inc VAT

Available to order

  • Ordered in from our supplier
    It usually reaches us the next working day and is dispatched the day it arrives
  • UK mainland delivery £11.00 ex VAT, free on orders over £75 inc VAT. Surcharge postcodes and international
Voltage
12V
Technology
Halogen
IP rating
IP59K

About this halogen work light

Halogen-Worklight - Modul 70 - 12V is a Hella halogen work light for 12V electrical systems. The light source is Halogen, the housing is sealed to IP59K. Mounting: mounting / bolted.

It is a universal fitting for tractors, trailers, telehandlers and other farm machinery, sold as a single unit unless the specification states a pack quantity.

The Agri Lighting part number is A25-005562 (previously PT/996176181), and it replaces or is equivalent to 1G0 996 176-181.

The Module 70 with H9 bulb is a compact worklight with an extremely small installation space. Despite its small size, the free-form reflector made of die-cast aluminium produces excellent light output. Thanks to the optics-free, hardened diffusing lens, the unit shines with the most modern design. Versions for illuminating the near working area or with long-range illumination are optionally available. The use of the H9 bulb results in significant advantages for the customer. The robust headlamp housing is made of glass-fibre reinforced plastic and is resistant to acid and corrosion. Due to its compact dimensions, the worklight can be used universally. The housing is firmly glued to the reflector and the diffusing lens. The plug-in connection is made directly via the bulb. Fast, tool-free bulb replacement is guaranteed with all versions. This headlamp is available as a surface-mounted headlamp (depending on the version: upright, or suspended) and as a recessed version.

  • The H9 bulb offers 50% better light output than an H3 bulb.
  • With the optic-free, hardened diffusing lens, the unit shines with a modern design.
  • The robust headlamp housing is made of glass fibre reinforced plastic and is acid and corrosion resistant.
  • Thanks to its compact dimensions, the worklight can be used universally.
  • Lamp Type: H9 - Power consumption: 65W
  • Patterned diffusing lens
  • Prot.type (IP Code): IP5K9K

Specifications

Voltage12V
TechnologyHalogen
IP ratingIP59K
Mountingmounting / Bolted
FasteningSuspended / Swivelling Mounting Bracket
Bulb typeH9
Height113 mm
Width83 mm
Depth89 mm
Light distributionShort distance lighting
Connectoropen cable ends
Power consumption65 W
Cable2000 mm
Housing typeSynthetic Material Housing
Housing colourBlack
Diffusing lens materialPolyamid 12
Diffusing lens typePatterned diffusing lens
Weight453 g
Part numberA25-005562
BrandHella

Part numbers

Our part number for this item is A25-005562. It was previously listed as PT/996176181, and either number finds it in the search.

This part replaces or is equivalent to the following numbers. Use them to match an existing lamp or a dealer quote.

  • 1G0 996 176-181
