LED-Worklight – Flat Beam 500 – 12/24V
🚚 Estimated delivery: 3 Working Days
£102.20£102.20 Incl. VATExcl. VAT
In stock
The Flat Beam 500 LED from HELLA is a compact LED worklight with an elegant design. The housing depth of only 30 mm is ideal for mounting situations with little space. The light disk of the Flat Beam 500 LED was specially developed so that even when mounted on a flat wall, the light beams are directed towards the floor at a 45° angle. This ensures good illumination of the working area even when mounted flat. This highly efficient worklight features 30 energy-efficient LEDs that consume only 7 watts of power. To achieve the same amount of light with a 12 volt halogen headlamp, 55 watts (e.g. H3) are needed. The reduced energy consumption of the vehicle minimises energy costs and protects the environment. The light output of 550 lumens is sufficient to homogeneously illuminate the working environment in the near-field area. This worklight can be operated with either 12 or 24 volts. The integrated electronics protect the unit in the event of reverse polarity and ensures constant brightness even with a fluctuating operating voltage of 9 to 32 volts. The extremely flat design allows flexible mounting options, e.g. on the rear wall of trucks. Thanks to its plastic housing, the Flat Beam 500 LED is not susceptible to corrosion and is therefore ideal for use under the toughest conditions.
- 30 energy-efficient LEDs are installed in this highly efficient worklight.
- The housing depth of only 30 mm is ideal for mounting situations with limited space.
- The lens of the Flat Beam 500 has been specially developed so that even when mounted on a flat wall, the light beams are directed towards the floor at an angle of 45°.
- The reduced energy consumption of the vehicle saves a lot of energy costs and at the same time protects the environment.
- This worklight is not susceptible to corrosion due to its plastic housing and is therefore ideal for use under the toughest conditions.
- Lamp Type: LED – Number of LEDs: 30 – Power consumption: 7W – Colour Temperature: 5700K
- Patterned diffusing lens
We aim to dispatch all orders within one working day of payment.
Standard UK delivery takes around 3 working days from dispatch.
Delivery details:
Free UK delivery on most orders over £75.
Express and international shipping options available at checkout.
Tracking details sent by email once your order leaves our warehouse.
Returns:
Returns accepted within 30 days of receipt if unused and in original packaging.
Faulty or incorrect items: contact us for a prepaid return label.
Refunds processed within 3–5 days of receiving your return.
For full details, visit our Delivery & Returns Policy
Additional information
| Weight | 0.31 kg |
|---|---|
| Dimensions | 143 × 95 × 125 cm |
| Private Equivalent | 995193021 |
| Equivalent Parts | 1GA 995 193-021, 8500050, 995193021 |
| Mounting Type | mounting / Bolted |
| Fastening Type | 2-point attachment |
| Light Design | LED |
| Lamp Type | LED |
| Voltage | 12 V / 24 V |
| Height | 117 mm |
| Width | 113 mm |
| Depth | 31 mm |
| Light Distribution | Short distance lighting |
| fulfils ECE norm | R10 |
| Plug | open cable ends |
| Prot.type (IP Code) | IP6K7 / IP6K9K |
| Luminous Flux | 500 lm |
| Colour Temperature | 5700 K |
| Number of LEDs | 30 |
| Power consumption | 7 W |
| Cable | 2000 mm |
| Housing Type | Synthetic Material Housing |
| Housing Colour | black |
| Diffusing Lens Material | Glass |
| Diffusing Lens Type | Patterned diffusing lens |
