Asymmetric/LED/DE-Insert, headlight – 90mm Essential L4565 – 12/24V
🚚 Estimated delivery: 3 Working Days
£218.06£218.06 Incl. VATExcl. VAT
In stock
HELLA 90mm modular headlights stand for the highest quality, reliability and cost efficiency. Whether bus, tractor, truck, motorhome or motorbike: The robust HELLA 90mm front headlights are used in many vehicle types. Thanks to their modular design, they offer maximum flexibility, which allows a wide range of applications as well as an individual front design. Within the 90mm modular headlamp range, a choice can be made between halogen and LED technology depending on requirements, which also facilitates the switch from halogen to LED. All modules score with a robust design and can therefore also be used in demanding working environments. The difference between the individual series of the 90mm range lies in the details. The L4060 LED modules, for example, shine with outstanding light output and additional lighting functions. The light colour of the LED modules, which is similar to daylight, significantly improves visibility and the ability to concentrate when driving at night, thus increasing safety. The L4565 Bi-LED modules as well as the BI-Halogen modules combine low beam and high beam in a single headlamp module and are therefore ideally suited for construction situations with limited space. The R80 modules have an innovative reflector design that ensures particularly homogeneous lighting.
- Excellent low beam and high beam from a single headlamp module
- Design freedom through modular system
- For the most diverse applications and maximum demands
- The die-cast aluminium housing and the robust design allow the use in rough environments and under maximum demands
- In addition to the high resistance to vibration, which makes this product ideal for use in construction machinery, the Bi-LED module with IP 67 protection class is particularly dustproof and resistant to high-pressure cleaning
- Ø: 94mm – Length: 135mm – Width: 124mm – Height: 135mm – Depth: 74mm – Lamp Type: LED – without bulb – Electromagnetic Compatibility (EMC)
- Light functions: 2 – with high beam (LED)/with low beam (LED)
We aim to dispatch all orders within one working day of payment.
Standard UK delivery takes around 3 working days from dispatch.
Delivery details:
Free UK delivery on most orders over £75.
Express and international shipping options available at checkout.
Tracking details sent by email once your order leaves our warehouse.
Returns:
Returns accepted within 30 days of receipt if unused and in original packaging.
Faulty or incorrect items: contact us for a prepaid return label.
Refunds processed within 3–5 days of receiving your return.
For full details, visit our Delivery & Returns Policy
Additional information
| Weight | 1.307 kg |
|---|---|
| Dimensions | 190 × 143 × 125 cm |
| Private Equivalent | 015318001 |
| Equivalent Parts | 1AL 015 318-001, 24675419, 24470509, ACX3295770, ACX3295850, 015318001 |
| Mounting Type | Fitting / mounting |
| Fastening Type | Four-point attachment |
| Light Design | Asymmetric / DE / LED |
| Lamp Type | LED |
| Voltage | 12 V / 24 V |
| Fitting Position | left / right |
| Height | 135 mm |
| Width | 124 mm |
| Length | 135 mm |
| Depth | 74 mm |
| Ø | 94 mm |
| Light Function | with high beam (LED) / with low beam (LED) |
| Light functions | 2 |
| fulfils ECE norm | R149 / R10 |
| Registration Type | CCC |
| Plug | DEUTSCH plug |
| Reference number | 17.5 |
| Left-hand/Right-hand Traffic | for right-hand traffic |
| Lens Colour | Crystal clear |
| Housing Colour | black |
| Illuminated Area | 94 mm |
| Shape | round |
| Diffusing Lens Material | Glass |
| Supplementary Article/Info 2 | Electromagnetic Compatibility (EMC) |
| Supplementary Article/Supplementary Info | without bulb |
| Quantity | 1 |
