Rearlight - Bulb - 12V

Hella Part no. A25-000309 Previously PT/001685307

Rearlight - Bulb - 12V

Shop rating 4.3, from 4 customer reviews of Agri Lighting
£45.85 ex VAT
£55.02 inc VAT

Available to order

  • Ordered in from our supplier
    It usually reaches us the next working day and is dispatched the day it arrives
  • UK mainland delivery £11.00 ex VAT, free on orders over £75 inc VAT. Surcharge postcodes and international
Voltage
12V
Technology
Bulb
Lens colour
Amber, Red
Light functions
Brake light, Indicator, Tail light
IP rating
IP54K

About this rear lamps bulb

Rearlight - Bulb - 12V is a Hella rear lamps bulb for 12V electrical systems. The light source is Bulb, the lens is amber, red, the housing is sealed to IP54K. Light functions: brake light, indicator, tail light. Mounting: bolted / mounting.

It is a universal fitting for tractors, trailers, telehandlers and other farm machinery, sold as a single unit unless the specification states a pack quantity.

The Agri Lighting part number is A25-000309 (previously PT/001685307), and it replaces or is equivalent to 2SD 001 685-307, 108300002900, 5217878, 5641363, 76112026, 3698768 and 1 more.

HELLA combination rear lamps. A crowning finish for the rear of the vehicle. In road traffic, communication often takes place via light signals - which is why reliable lights from HELLA are indispensable for road safety. For these luminaires, too, we rely on the highest quality and the use of efficient technologies. HELLA combination rearlights are also characterised by outstanding quality in terms of workmanship and stability - the long service life proves it. The wide range of variants gives the vehicle an individual and unique look. The combination options open up attractive styling possibilities for an unmistakable, brand-typical appearance, which is also playing an increasing role in vehicles in the commercial vehicle and agricultural sectors.

  • Tail-stop-indicator lamp for horizontal surface-mounting (left / right) - with ECE approval
  • The combination rearlight has 3 light functions: Stop light / tail light / indicator - tail light and stop light red, indicator yellow
  • Lamp type: P21W/R5W, without bulbs, with vibration damping and grommet, black metal housing, 2 fixing screws M6, with especially heat-resistant PC lens
  • Length: 140mm - Height: 80mm - Lamp Type: R5W/P21W - without bulbs
  • Light functions: 3 - with indicator/with taillight/with stop light
  • Registration Type: ECE/ADR/GGVS/no SAE - Prot.type (IP Code): IP5K4K
  • Housing Colour: Black - Lens Colour: Red/Yellow

Specifications

Voltage12V
TechnologyBulb
Lens colourAmber, Red
Light functionsBrake light, Indicator, Tail light
IP ratingIP54K
MountingBolted / mounting
Fasteningfor horizontal fastening
Bulb typeP21W / R5W
Fitting positionleft / right
Height80 mm
Length140 mm
ConnectorBlade Terminal
Housing colourBlack
Weight448 g
Part numberA25-000309
BrandHella

Part numbers

Our part number for this item is A25-000309. It was previously listed as PT/001685307, and either number finds it in the search.

This part replaces or is equivalent to the following numbers. Use them to match an existing lamp or a dealer quote.

  • 2SD 001 685-307
  • 108300002900
  • 5217878
  • 5641363
  • 76112026
  • 3698768
  • 76112016
