Side Marker Light - Halogen - 12V

Hella Part no. PT/006717031

Side Marker Light - Halogen - 12V

5.0 Excellent, from 2 customer reviews
£5.52 inc VAT
£4.60 ex VAT

In stock, 100 available

  • Dispatched within 1 working day
    UK mainland delivery usually takes 2 to 3 working days
  • UK mainland delivery £6.50, free on orders over £75 inc VAT. Surcharge postcodes and international

In stock

Voltage
12V
Technology
Halogen
Lens colour
Amber
Light functions
Reflector, Side marker
IP rating
IP59K

About this side marker lamp

Side Marker Light - Halogen - 12V is a Hella side marker lamp for 12V electrical systems. The light source is Halogen, the lens is amber, the housing is sealed to IP59K. Light functions: reflector, side marker. Mounting: screw connection / mounting. It carries R3 / R91 approval for road use.

It is a universal fitting for tractors, trailers, telehandlers and other farm machinery, sold as a single unit unless the specification states a pack quantity.

The Agri Lighting part number is PT/006717031, and it replaces or is equivalent to 2PS 006 717-031, 42225071, 1302727, 8933741104, 88252606012, ZFHR67170376238 and 43 more.

HELLA side marker lights. Side marker lights are an important safety feature that make the outline of a vehicle more visible to other road users, especially in the dark. Especially vehicles with large dimensions such as combine harvesters, long transporters, etc. can be displayed much better in this way. In some countries, active side marker lights are required by law from a certain vehicle length. HELLA side marker lights meet the highest requirements even in demanding fields of application and impress with their durability and the well-known high HELLA quality.

  • Side marker reflector light for side mounting (horizontal / vertical, left / right) - with ECE approval, ADR/GGVS-tested
  • The side marker light has 2 light functions: Side marker light / reflector
  • Lamp type: W5W, without bulb, housing made of black plastic, 2 holes Ø 5 mm for fixing screws
  • Length: 110mm - Width: 40mm - Height: 25mm - Lamp Type: W5W - without bulb
  • Light functions: 2 - with side marker light/with reflector
  • Registration Type: ADR/GGVS - fulfils ECE norm: R3/R91 - Prot.type (IP Code): IP5K9K
  • Synthetic Material Housing - Housing Colour: Black - Lens Colour: Yellow

Specifications

Voltage12V
TechnologyHalogen
Lens colourAmber
Light functionsReflector, Side marker
IP ratingIP59K
MountingScrew Connection / mounting
Fasteningfor vertical fastening / for horizontal fastening
Bulb typeW5W
Fitting positionright / left
Height25 mm
Width40 mm
Length110 mm
ECE approvalR3 / R91
Housing typeSynthetic Material Housing
Housing colourblack
Power consumption5 W
Weight53 g
Part numberPT/006717031
BrandHella

Part numbers

This part replaces or is equivalent to the following numbers. Use them to match an existing lamp or a dealer quote.

  • 2PS 006 717-031
  • 42225071
  • 1302727
  • 8933741104
  • 88252606012
  • ZFHR67170376238
  • 170005
  • 1906671
  • 20044864
  • 20223840
  • 10520602
  • 5241380
  • 7000939
  • 99707000939
  • F024693
  • D45000268
  • 657036
  • 2292413
  • 511091
  • 4108228A
  • EP0002907
  • 607138101
  • 607142708
  • 63456540
  • 14330405H91
  • 4405143
  • 85759
  • FE0435
  • 14090000
  • 821PL007
  • 821PL007A
  • 56115
  • B170036
  • 60977
  • 46130
  • 401880
  • 1402006717037
  • LSX0498001
  • 5006566
  • 11306
  • 11779
  • 7011174
  • 58086730
  • 1020018815
  • 11967
  • 59101
  • 2791667
  • 20223492
  • 161248
