Position Light - Shapeline Style - LED - 24/12V

Hella Part no. PT/013326081

Position Light - Shapeline Style - LED - 24/12V

5.0 Excellent, from 2 customer reviews
£28.46 inc VAT
£23.72 ex VAT

In stock, 100 available

  • Dispatched within 1 working day
    UK mainland delivery usually takes 2 to 3 working days
  • UK mainland delivery £6.50, free on orders over £75 inc VAT. Surcharge postcodes and international

In stock

Voltage
12/24V
Technology
LED
Lens colour
Clear, White
Light functions
Position light
IP rating
IP67

About this position lamp

Position Light - Shapeline Style - LED - 24/12V is a Hella position lamp for 12/24V electrical systems. The light source is LED, the lens is clear, white, the housing is sealed to IP67. Light functions: position light. Mounting: mounting / glued. It carries R7 approval for road use.

It is a universal fitting for tractors, trailers, telehandlers and other farm machinery, sold as a single unit unless the specification states a pack quantity.

The Agri Lighting part number is PT/013326081, and it replaces or is equivalent to 2PF 013 326-081.

HELLA Shapeline. The variety of shapes and different combination options coupled with a technically optimised product design make the Shapeline luminaire range an innovation in the field of vehicle lighting! Whether at the front, side or rear of the vehicle, any vehicle series - whether small or large - can be given an individual and, above all, consistent appearance via an individual composition and arrangement of the lights. In addition to innovative technology and the well-known high HELLA quality, the variety of shapes of the Shapeline luminaires offers you almost limitless design freedom.

  • Flexible design with the classic straight Shapeline Tech Design and the curved dynamic Shapeline Style Design
  • Wide range of functions thanks to numerous LED lighting functions that can be combined in different, individual ways
  • High recognition value thanks to unique yet consistent light signature
  • LED technology ensures long service life and energy efficiency
  • Simple and safe installation
  • Length: 198mm - Width: 40mm - Height: 41mm - Lamp Type: LED - Number of LEDs: 6
  • Light functions: 1 - with position light (LED)

Specifications

Voltage12/24V
TechnologyLED
Lens colourClear, White
Light functionsPosition light
IP ratingIP67
Mountingmounting / Glued
Fasteningfor vertical fastening
Bulb typeLED
Fitting positionRight Front
Height41 mm
Width40 mm
Length198 mm
ConnectorAMP
ECE approvalR7
Number of LEDs6
Led colourwhite
Housing colourblack
Power consumption2.1 W
Shapeslim
Weight103 g
Part numberPT/013326081
BrandHella

Part numbers

This part replaces or is equivalent to the following numbers. Use them to match an existing lamp or a dealer quote.

  • 2PF 013 326-081
