LED-Insert, headlight - 90mm Performance L4565 - 12/24/9/33V
5.0 Excellent, from 2 customer reviewsIn stock, 100 available
-
Dispatched within 1 working day
UK mainland delivery usually takes 2 to 3 working days - UK mainland delivery £11.00, free on orders over £75 inc VAT. Surcharge postcodes and international
In stock
- 30-day returns
- Secure card payment via Stripe
- Call 01522 440522, Mon to Fri, 9am to 5pm
- Voltage
- 12/24V
- Technology
- LED
- Light functions
- Dipped beam, High beam
About this tractor headlight
LED-Insert, headlight - 90mm Performance L4565 - 12/24/9/33V is a Hella tractor headlight for 12/24V electrical systems. The light source is LED. Light functions: dipped beam, high beam. Mounting: mounting.
It is a universal fitting for tractors, trailers, telehandlers and other farm machinery, sold as a single unit unless the specification states a pack quantity.
The Agri Lighting part number is PT/015318041, and it replaces or is equivalent to 1LL 015 318-041.
HELLA 90mm modular headlights stand for the highest quality, reliability and cost efficiency. Whether bus, tractor, truck, motorhome or motorbike: The robust HELLA 90mm front headlights are used in many vehicle types. Thanks to their modular design, they offer maximum flexibility, which allows a wide range of applications as well as an individual front design. Within the 90mm modular headlamp range, a choice can be made between halogen and LED technology depending on requirements, which also facilitates the switch from halogen to LED. All modules score with a robust design and can therefore also be used in demanding working environments. The difference between the individual series of the 90mm range lies in the details. The L4060 LED modules, for example, shine with outstanding light output and additional lighting functions. The light colour of the LED modules, which is similar to daylight, significantly improves visibility and the ability to concentrate when driving at night, thus increasing safety. The L4565 Bi-LED modules as well as the BI-Halogen modules combine low beam and high beam in a single headlamp module and are therefore ideally suited for construction situations with limited space. The R80 modules have an innovative reflector design that ensures particularly homogeneous lighting.
- Excellent lighting performance of dipped beam and main beam from a single headlamp module
- "Zero Tolerance Integration" creates new design freedom
- For demanding applications
- Lamp Type: LED
- Light functions: 2 - with low beam (LED)/with high beam (LED)
- Registration Type: ECE - for left-hand traffic
- Mounting Type: mounting
Specifications
| Voltage | 12/24V |
|---|---|
| Technology | LED |
| Light functions | Dipped beam, High beam |
| Fitting position | Front |
| Mounting | mounting |
| Bulb type | LED |
| Power consumption | 40 W |
| Connector | DEUTSCH plug |
| Left-hand/right-hand traffic | for left-hand traffic |
| Weight | 1.57 kg |
| Part number | PT/015318041 |
| Brand | Hella |
Part numbers
This part replaces or is equivalent to the following numbers. Use them to match an existing lamp or a dealer quote.
- 1LL 015 318-041
