Asymmetric-Headlight - C240 - 12/24V

Hella Part no. PT/328550281

Asymmetric-Headlight - C240 - 12/24V

5.0 Excellent, from 2 customer reviews
£249.25 inc VAT
£207.71 ex VAT

In stock, 100 available

  • Dispatched within 1 working day
    UK mainland delivery usually takes 2 to 3 working days
  • UK mainland delivery £11.00, free on orders over £75 inc VAT. Surcharge postcodes and international

In stock

Voltage
12/24V
Technology
LED
Light functions
Dipped beam, High beam, Indicator, Position light
IP rating
IP69K

About this tractor headlight

Asymmetric-Headlight - C240 - 12/24V is a Hella tractor headlight for 12/24V electrical systems. The light source is LED, the housing is sealed to IP69K. Light functions: dipped beam, high beam, indicator, position light. Mounting: bolted. It carries R149 / R10 / R148 approval for road use.

It is a universal fitting for tractors, trailers, telehandlers and other farm machinery, sold as a single unit unless the specification states a pack quantity.

The Agri Lighting part number is PT/328550281, and it replaces or is equivalent to 1LF 328 550-281.

The C240 LED is a combination headlight in which all lighting functions are implemented using LED technology. The special free-form reflector in conjunction with the LED light source provides significantly better light than headlights with halogen bulbs. Due to the light color being similar to daylight, the light appears significantly brighter to the eye and therefore enables fatigue-free work at night. The main headlight is particularly vibration and shock resistant. Ideal for harsh use on construction vehicles (high vibrations, dust, moisture, mechanical shock, etc.). Thanks to LED technology, a service life can be achieved. The lower LED power consumption compared to a conventional halogen headlight also leads to fuel savings, which can save further costs. The C240 LED meets all ECE and SAE requirements and is suitable and approved for almost worldwide use.

  • Class B asymmetric, LES, bottom mount, right
  • Prot.type (IP Code): IP6K9K
  • Housing material: PBT
  • with high beam (LED)/with low beam (LED)/with daytime running light (LED)/with position light (LED)/with indicator (LED)
  • Width: 245mm - Height: 252mm - Depth: 141mm - Lamp Type: LED - with indicator failure control
  • with high beam (LED)/with low beam (LED)/with position light (LED)/with indicator (LED)
  • Registration Type: ECE - fulfils ECE norm: R149/R148/R10 - for left-hand traffic - Prot.type (IP Code): IP6K9K

Specifications

Voltage12/24V
TechnologyLED
Light functionsDipped beam, High beam, Indicator, Position light
IP ratingIP69K
Fitting positionright
MountingBolted
FasteningVertical fastening
Left-hand/right-hand trafficfor left-hand traffic
Bulb typeLED
ECE approvalR149 / R10 / R148
Housing materialPBT
Temperature range from-40 °C
Temperature range to+50 °C
ConnectorDEUTSCH plug
Number of pins6 -pin connector
Height252 mm
Width245 mm
Depth141 mm
Reverse polarity protectionYes
Paired article number1LF 328 550-271
Weight2.67 kg
Part numberPT/328550281
BrandHella

Part numbers

This part replaces or is equivalent to the following numbers. Use them to match an existing lamp or a dealer quote.

  • 1LF 328 550-281
