DE/Halogen-Headlight - 90mm Performance - 12V

Hella Part no. PT/009998001

DE/Halogen-Headlight - 90mm Performance - 12V

5.0 Excellent, from 2 customer reviews
£82.72 inc VAT
£68.93 ex VAT

In stock, 100 available

  • Dispatched within 1 working day
    UK mainland delivery usually takes 2 to 3 working days
  • UK mainland delivery £11.00, free on orders over £75 inc VAT. Surcharge postcodes and international

In stock

Voltage
12V
Technology
Halogen
Light functions
Dipped beam, High beam

About this tractor headlight

DE/Halogen-Headlight - 90mm Performance - 12V is a Hella tractor headlight for 12V electrical systems. The light source is Halogen. Light functions: dipped beam, high beam. Mounting: fitting.

It is a universal fitting for tractors, trailers, telehandlers and other farm machinery, sold as a single unit unless the specification states a pack quantity.

The Agri Lighting part number is PT/009998001, and it replaces or is equivalent to 1AL 009 998-001, 50525990, 21659480, 280393130, 72477446, G260900020020 and 21 more.

HELLA front lighting. Look ahead - with front lighting solutions from HELLA. Nothing works without powerful headlights - neither on the road nor in the field. They are the vehicle's eyes, so to speak, and thus an essential safety feature when driving and working at night. HELLA's 90 mm front lighting modules are particularly tailored to the needs of trucks and agricultural vehicles and are used in almost all vehicles and situations due to their functional diversity. The modules are small, but powerful - and offer a high degree of flexibility thanks to the modular concept, which allows numerous possible applications, especially in the truck and agricultural sectors. Thanks to the future-proof HELLA upgrade concept, even the classic halogen modules can later be converted to the efficient, bright LED technology that already characterises the majority of the modules.

  • Individual front design thanks to modular construction
  • Numerous application possibilities even in more demanding environments
  • Excellent light output and extremely homogeneous illumination with little scattered light from a 70 mm optic-free lens
  • Simple installation with pre-mounted adjusting screws
  • Width: 182mm - Height: 108mm - Depth: 182mm - Lamp Type: H7 - with bulb - with bulbs/Electromagnetic Compatibility (EMC)
  • Light functions: 2 - with low beam/with high beam
  • Registration Type: ECE/CCC/SAE - for right-hand traffic

Specifications

Voltage12V
TechnologyHalogen
Light functionsDipped beam, High beam
MountingFitting
Bulb typeH7
Fitting positionright / left
Width182 mm
Height108 mm
Depth182 mm
Outer diameter108 mm
ConnectorAMP
Left-hand/right-hand trafficfor right-hand traffic
Shaperound
Illuminated area90 mm
Diffusing lens materialGlass
Weight783 g
Part numberPT/009998001
BrandHella

Part numbers

This part replaces or is equivalent to the following numbers. Use them to match an existing lamp or a dealer quote.

  • 1AL 009 998-001
  • 50525990
  • 21659480
  • 280393130
  • 72477446
  • G260900020020
  • G334900160020
  • G334900160021
  • 46421
  • 6603320A1
  • 3005785
  • 5390528
  • 63595600
  • 20G0651530
  • 900530209
  • 5104150000
  • 200842950
  • NA298
  • A12X21302202
  • 1640519
  • 1893941
  • 1893941H
  • 8015920
  • X160315164
  • 3062615
  • V63595600
  • 12.5

Delivery and returns

In-stock orders placed before 3pm on a working day are dispatched the same day from our Lincolnshire warehouse, with tracking sent by email. UK mainland delivery for this item is £11.00, and it is free on orders over £75 inc VAT. Highlands, islands and other surcharge postcodes are priced at checkout, and international delivery is priced by zone.

Unused items in their original packaging can be returned within 30 days of delivery; you pay the return postage and there is no restocking fee on stock items. Every part carries a 12-month warranty, and for a faulty or incorrectly supplied item we send a prepaid return label and replace or refund it. Full details are on the delivery and returns page.
