Halogen/FF-Front Fog Light - Dynaview Evo2 - 12V
Shop rating 4.3, from 4 customer reviews of Agri LightingAvailable to order
-
Ordered in from our supplier
It usually reaches us the next working day and is dispatched the day it arrives - UK mainland delivery £11.00 ex VAT, free on orders over £75 inc VAT. Surcharge postcodes and international
- 30-day returns
- Secure card payment via Stripe
- Call 01522 440522, Mon to Fri, 9am to 5pm
- Voltage
- 12V
- Technology
- Halogen
- Lens colour
- Clear
- Light functions
- Fog light
About this fog lamp
Halogen/FF-Front Fog Light - Dynaview Evo2 - 12V is a Hella fog lamp for 12V electrical systems. The light source is Halogen, the lens is clear. Light functions: fog light. Mounting: fitting. It carries R19 approval for road use.
It is a universal fitting for tractors, trailers, telehandlers and other farm machinery, sold as a single unit unless the specification states a pack quantity.
The Agri Lighting part number is A25-001526 (previously PT/009295021), and it replaces or is equivalent to 1N0 009 295-021, 2048202256, A2048202256.
The DynaView® Evo2 combines the cornering light and fog light safety functions in a compact round universal light. The cornering light is automatically activated whenever the vehicle takes a bend. When the vehicle comes out of the bend, a dimmer softly fades the extra light. Pendant or vertical mounting guarantees easy and convenient fixing. The cornering light and fog light constellation is ideal when combined with the matching 90 mm high-beam and low-beam headlamps. The fastening clamp or the carrier frame, whichever is the case, is included in the scope of delivery.
- Halogen cornering and fog lights with FF technology
- Crystal clear optical diaphragm
- Vertical or suspended mounting
- Ø: 90mm - Width: 96mm - Height: 116mm - Depth: 94mm - Fitting Depth: 94mm - Lamp Type: H7 - with bulb - with fastening clamp
- Light functions: 2 - with cornering light/with front fog light
- Registration Type: CCC/ECE/SAE - fulfils ECE norm: R19
- Housing Colour: Black - Lens Colour: transparent
Specifications
| Voltage | 12V |
|---|---|
| Technology | Halogen |
| Lens colour | Clear |
| Light functions | Fog light |
| Mounting | Fitting |
| Fastening | Vertical / Suspended |
| Bulb type | H7 |
| Fitting position | right |
| Height | 116 mm |
| Width | 96 mm |
| Depth | 94 mm |
| Fitting depth | 94 mm |
| Ø | 90 mm |
| ECE approval | R19 |
| Housing colour | black |
| Illuminated area | 90 mm |
| Shape | round |
| Diffusing lens type | Clear diffusing lens |
| Paired article number | 1N0 009 295-011 |
| Weight | 383 g |
| Part number | A25-001526 |
| Brand | Hella |
Part numbers
Our part number for this item is A25-001526. It was previously listed as PT/009295021, and either number finds it in the search.
This part replaces or is equivalent to the following numbers. Use them to match an existing lamp or a dealer quote.
- 1N0 009 295-021
- 2048202256
- A2048202256
Delivery and returns
This item is ordered in from our supplier. It usually reaches us the next working day and is dispatched the day it arrives, with tracking sent by email. UK mainland delivery for this item is £11.00 ex VAT, and it is free on orders over £75 inc VAT. Highlands, islands and other surcharge postcodes are priced at checkout, and international delivery is priced by zone.
Unused items in their original packaging can be returned within 30 days of delivery; you pay the return postage and there is no restocking fee on stock items. Every part carries a 12-month warranty, and for a faulty or incorrectly supplied item we send a prepaid return label and replace or refund it. Full details are on the delivery and returns page.
